Code: FPS331/349
from
INC VAT
Code: FPS331/349
Windowmaster WMU 836 Chain Actuator (300N) for use as an AOV or OV Actuator on most windows and lightweight roof vents and domes.
Window Master WMU 836 Chain Actuator | ||
Smoke ventilation B300 | Smoke ventilation EN 12101 | WMU 836600 |
UL certification – Actuators | Suitable for most window types | Synchronisation of up to 4 Actuators |
Synchronisation of up to 4 Actuators | Programmable features - stroke size, team size, speed | Supplied with a 5.0m cable |
Fixing brackets sold separately | EN12101-2 compliant | Natural ventilation |
±24V control | MotorLink | |
Window Master WMU 836 Chain Actuator | |||
Voltage | 24V DC (+/- 10%) | Pull Force | 300N |
Opening Stroke | 600mm (programmable) | Locking Force | 3000N |
Current Consumption | 1.0 A | Opening Speed | 14 mm/s (programmable) |
Switch-on Duration | ED 40% (max. 4min. per 10min) | Operating Conditions | -5°C - +74°C, max. 90% relative humidity (not condensing) |
IP Rating | IP32 | Colour | Silver Anodised |
Flex Length | 5m | Life Span | 10,000 opening and closing movements |
Min. window width | > 828 mm | Cable Dimensions | 2-Core (plus 1 communication wire) |
Synchronisation | Yes | Max. window width | < 1300 mm (use multiple actuators if wider) |
Windowmaster WMU 836 Chain Actuator (300N) for use as an AOV or OV Actuator on most windows and lightweight roof vents and domes.
Window Master WMU 836 Chain Actuator | ||
Smoke ventilation B300 | Smoke ventilation EN 12101 | WMU 836600 |
UL certification – Actuators | Suitable for most window types | Synchronisation of up to 4 Actuators |
Synchronisation of up to 4 Actuators | Programmable features - stroke size, team size, speed | Supplied with a 5.0m cable |
Fixing brackets sold separately | EN12101-2 compliant | Natural ventilation |
±24V control | MotorLink | |
Window Master WMU 836 Chain Actuator | |||
Voltage | 24V DC (+/- 10%) | Pull Force | 300N |
Opening Stroke | 600mm (programmable) | Locking Force | 3000N |
Current Consumption | 1.0 A | Opening Speed | 14 mm/s (programmable) |
Switch-on Duration | ED 40% (max. 4min. per 10min) | Operating Conditions | -5°C - +74°C, max. 90% relative humidity (not condensing) |
IP Rating | IP32 | Colour | Silver Anodised |
Flex Length | 5m | Life Span | 10,000 opening and closing movements |
Min. window width | > 828 mm | Cable Dimensions | 2-Core (plus 1 communication wire) |
Synchronisation | Yes | Max. window width | < 1300 mm (use multiple actuators if wider) |
