The Vimpex IL-MINI-2 Identi-Leak Mini Panel is a compact, 2-zone water leak detection unit designed for localized or small-scale monitoring applications.
Each zone supports connection to either detection cable or point-type probes, providing flexible detection options tailored to the specific risk area.
The panel includes clear visual indicators for power, fault, and alarm status per zone, allowing for quick and easy issue identification. An integrated sounder delivers audible alerts, while volt-free relays enable seamless integration with external systems such as BMS or solenoid valves.
Its DIN-rail mountable design makes the IL-MINI-2 ideal for installation in equipment enclosures, server racks, or confined spaces where space is limited but protection is essential.
Compact, reliable, and easy to install, the IL-MINI-2 is a practical solution for targeted leak detection in critical environments.
Product code: IL-MINI-2
Monitors up to 2 separate detection zones
Supports probes and detection cable
Local sounder and LED status indicators
Volt-free alarm and fault relays
DIN-rail mountable for compact spaces
Ideal for server rooms and equipment enclosures
Specification | Details |
|---|---|
Mains Supply | 230 Vac |
Output Voltage | 28.5 V nominal Vdc |
Battery Size Max | 12 Vdc 1.2Ah (2 Batteries) |
Dedicated Sounder Circuits | 24 Vdc, fused at 300 mA |
Detection Circuit EOL | Active EOL – Capacitor |
Sounder Circuit EOL | 10K Ohms, 0.25 W |
IP Rating | 30 |
Operating Temperature | -10ºC to 50ºC |
Construction | Fire Rated ABS |
Colour | White |
Dimensions (H × W × D) | 256 × 194 × 86 mm |
Weight | 1.1 Kg |
The Vimpex IL-MINI-2 Identi-Leak Mini Panel is a compact, 2-zone water leak detection unit designed for localized or small-scale monitoring applications.
Each zone supports connection to either detection cable or point-type probes, providing flexible detection options tailored to the specific risk area.
The panel includes clear visual indicators for power, fault, and alarm status per zone, allowing for quick and easy issue identification. An integrated sounder delivers audible alerts, while volt-free relays enable seamless integration with external systems such as BMS or solenoid valves.
Its DIN-rail mountable design makes the IL-MINI-2 ideal for installation in equipment enclosures, server racks, or confined spaces where space is limited but protection is essential.
Compact, reliable, and easy to install, the IL-MINI-2 is a practical solution for targeted leak detection in critical environments.
Product code: IL-MINI-2
Monitors up to 2 separate detection zones
Supports probes and detection cable
Local sounder and LED status indicators
Volt-free alarm and fault relays
DIN-rail mountable for compact spaces
Ideal for server rooms and equipment enclosures
Specification | Details |
|---|---|
Mains Supply | 230 Vac |
Output Voltage | 28.5 V nominal Vdc |
Battery Size Max | 12 Vdc 1.2Ah (2 Batteries) |
Dedicated Sounder Circuits | 24 Vdc, fused at 300 mA |
Detection Circuit EOL | Active EOL – Capacitor |
Sounder Circuit EOL | 10K Ohms, 0.25 W |
IP Rating | 30 |
Operating Temperature | -10ºC to 50ºC |
Construction | Fire Rated ABS |
Colour | White |
Dimensions (H × W × D) | 256 × 194 × 86 mm |
Weight | 1.1 Kg |
